Champion VRV7-8S 7.5HP Two-Stage 80 Gallon Vertical Tank Air Compressor(Champion 7 5hp 80 Gallon 1 Ph 230 V 4 Cylinder Vertical Compressor)

Champion VRV7-8S 7.5HP Two-Stage 80 Gallon Vertical Tank Air Compressor

With Champion, you not only get value, but you also get the confidence that comes with owning a solid, reliable compressor. The RV-Series exemplifies quality, reliability, long life, and tremendous value. Champion provides the total package—a low-cost solution with a broad range of options—saving money and providing peace of mind. This compressor features a 7.5 HP single-phase electric motor, a two-stage pump that delivers 29.8 CFM at 125 PSI, an 80-gallon vertical tank, and comes equipped with a magnetic starter. Please see below for more features and specifications.

Features And Specifications

Standard Features:

• Automatic Start/Stop Operation
• Magnetic Starter*
• ASME Coded Receiver
• NEMA Rated Electric Motors
• 0–300 PSIG Air Pressure Gauge on Tank
• Preset Pressure Switch

Pump Specifications:

• CFM Delivered at 125 PSI: 29.8
• CFM Delivered at 175 PSI: 24
• Pump RPM: 575
• Splash Lubricated Air Compressor Pump
• Two-Stage Design
• 100% Cast Iron Compressor Pump
• Alloy Steel Reed Valves
• Oil Level Sight Glass
• Oil Drain
• Deep Finned Intercooler
• Large, Cast Iron Flywheel
• Industrial Grade Intake Filter and Silencer
• All Pumps are Factory Tested

Motor and Tank:

• Motor HP: 7.5
• Single Phase
• 80-Gallon Vertical Tank
• Dimensions (L x W X H): 40.8" x 31.6" x 74.8"
• Approximate Weight: 710 LBS
